Mirror-type Beamsplitters

  • Mirror-type Beamsplitters
  • 更新時間:2012-05-03 11:01:33

    點擊次數:1393

    型  號:

    規  格:

    材  料:



  • 產品描述
  • 技術規格

●Product Description

Consists of a carefully generated transparent substrate with a partially reflective coating on one side and an Anti-Reflection coating on the second surface. These are usually designed to be used at an angle of 45 degrees. By making the second surface at a wedged angle to the first surface any residual ghost image can be made to fall outside of field of view of the following system

●Product Detail











●Specifications



Material: BK7
Surface Accuracy:  4-6 lambda
Surface Quality: 80-50
Edges: Cut
Coatings (45 degree both sides)
1st side: Dielectric (R/T as defined)±5% R/T at 550nm
2nd side AR 1/4 lambda MgF2 at 550nm:
